Advanced Design Features & Superior Pulling Performance
The Condux Tesmec line of pullers offers industry leading features like negative self-acting hydraulic brakes, integrated hydraulic dynamometers, hydraulic cooling systems, advanced user controls and more. Hydraulically controlled systems allow Condux Tesmec pullers to eliminate conductor galloping, providing utility contractors maximum pulling control.
Condux Tesmec pullers are designed to improve job site safety, while adding productivity and efficiency to every job.
PM1250 Hydraulic Puller
- Pulling force: 11,240 lbf (50 kN)
- Pulling: one rope up to 1⁄2 inch (13 mm) in diameter
- Bull-wheel diameter 14 inches (350 mm)
PM1450 Hydraulic Puller
- Pulling force: 22,500 lbf (100 kN)
- Stringing: one rope up to 5/8 inch (16 mm) in diameter
- Bull-wheel grooves: heat treated steel
PL1750 Hydraulic Puller
- Pulling force: 40,500 lbf (180 kN)
- Stringing: one rope up to 1 3/32 inch (28 mm) in diameter
- Bull-wheel grooves: heat treated steel
PL1950 Hydraulic Puller
- Pulling force: 63,000 lbf (280 kN)
- Stringing: one rope up to 1 15/32 inch (38 mm) in diameter
- Bull-wheel grooves: heat treated steel
